mudslayer
Tracklocross
Meet the mudslayer
Specs
| Tubing | Dedacciai Zero 25th anniversary |
| Dropouts | Stainless steel horizontal |
| Fork | Homemade segmented fork |
| Bottom bracket | BSC 68mm |
| Headset | External 1”1/8 (EC34/28.6 - EC34/30) |
| Seatpost diameter | 27,2mm |
| Spacing | 100mm front, 120mm rear |
| Tire clearance | 700 x 40mm |
| Approximative weight | Around 2600 grams in size Large (frame and uncut fork) |
| Brakes | none (optional cantilever bosses or flatmount bosses) |
The ultimate tracklocross frameset that's built to handle any terrain. This versatile bike is handcrafted with care and precision, from the frame to the fork, ensuring it's a work of art that's built to last.
We spent many hours designing and engineering the MudSlayer to ensure it delivers maximum performance and agility. Its custom geometry and lightweight design make it incredibly easy to handle, while the up to 700 x 40 mm tire clearance provides unbeatable traction and stability. Plus, with its barspin capabilities, the MudSlayer is the perfect choice for riders who want to take their skills to the next level.
So whether you're a seasoned off-road and tricks skills enthusiast or just looking for a do-it-all bike that can handle anything, the MudSlayer is the perfect choice.
Frame features
Welding type
Fillet brazed with a smooth filed finish
Seat Stays Shape
S-bend
Seat clamp
Brazed
Tube shape
Round and ovalized
Serial number
Stamp brass plate under the bottom bracket shell
Frameset pricing
from 2650 €
Pre-tax: 2208 €
Join the waiting list
Geometry
| mudslayer | XS / 50 | S / 52 | M / 54 | L / 56 | XL / 58 |
|---|---|---|---|---|---|
| A / Effective Top Tube | 500 | 525 | 545 | 565 | 590 |
| B / Seat tube (c to c) | 460 | 480 | 515 | 540 | 565 |
| C / Chainstay | 395 | 395 | 395 | 395 | 395 |
| D / BB drop | 60 | 60 | 60 | 60 | 60 |
| E / Head tube | 95 | 105 | 120 | 140 | 150 |
| F / Reach | 371 | 388 | 395 | 404 | 421 |
| G / Stack | 520 | 531 | 547 | 566 | 579 |
| H / Wheelbase | 942 | 964 | 976 | 991 | 1002 |
| I / Axle to crown | 390 | 390 | 390 | 390 | 390 |
| R / Fork rake | 40 | 40 | 40 | 40 | 40 |
| X / Seat tube angle | 76 | 75,5 | 74,5 | 74 | 73,5 |
| Y / Head tube angle | 72 | 72,5 | 73 | 73 | 74 |
Options
Water bottle bosses
+ 55 €
Zero or one pair included in price, more in option
Zero or one pair included in price, more in option
Cantilever bosses front and rear
+ 250 €
Cantilever bosses front or rear only
+ 150 €
Front flat mount 160mm bosses
+ 75 €
Columbus max tubing for frame and fork
+ 150 €
Stainless steel brazed head badge
+ 35 €
Integrated steel seat tube
+ 230 €
Comes its custom 3D printed aluminium seat mast
Comes its custom 3D printed aluminium seat mast
Custom stem
+ 320 €
Choose your length and stem angle
Choose your length and stem angle
Custom geometry
+ 150 €
Within our size chart, if you’re outside of the chart, we’ve got you covered for free!
Within our size chart, if you’re outside of the chart, we’ve got you covered for free!
Paint
Chameleon or Candy
Solid color painted logos
+ 180 €
Paint effect two colors
Solid color painted logos
+ 280 €
Paint effect one color
Solid color painted logos
+ 220 €
One color glitter
Solid color painted logos
+ 140 €
Three color fade
Solid color painted logos
+ 90 €
Two color fade
Solid color painted logos
included
Solid color
Solid color painted logos
included
Full custom on request (gold leaf, marble effect, splatter, chameleon fade or whatever you have in mind just get in touch with us and we will discuss it together)
Frameset pricing
from 2650 €
Pre-tax: 2208 €
Join the waiting list
