falcon disc
Road disc brakes
Meet the falcon disc
Specs
| Tubing | Oversized Dedacciai Zero |
| Dropouts | Paragon Stainless SnapRing (thru-axle 12mm) |
| Fork | Columbus futura SLX (tapered 1”1/4) |
| Bottom bracket | T47 68mm |
| Headset | Semi-integrated 1"¼ (ZS44/28.6 - EC44/33) |
| Seatpost diameter | 27,2mm |
| Spacing | 12 x 100 mm front, 12 x 142 mm rear |
| Tire clearance | 700 x 30 mm |
| Approximative weight | Around 1800 grams in size Medium (frame only) |
| Brakes | Flat Mount 140mm |
Warmly welcome the Falcon in its disc version, the ultimate road bike that's built for speed and performance. With its lightweight construction and oversized steel tubes, this bike is the perfect combination of strength, agility and comfort.
But the material isn’t everything - the Falcon boasts a responsive and sporty geometry that's designed to help you take your riding to the next level. Whether you're sprinting for the finish line or tackling a challenging climb, this bike is up to the task. The frameset is a work of art. Each frame is carefully crafted by hand, with meticulous attention to detail and an eye for beauty. And with a range of stunning paint options to choose from, you can customize your Falcon to perfectly match your style.
Frame features
Routing type
Internal not guided
Front derailleur mount
Clamped
Welding type
Fillet brazed with a smooth filed finish
Seat Stays Shape
Straight
Seat clamp
Brazed
Tube shape
Round
Serial number
Stamp brass plate under the bottom bracket shell
Frameset pricing
from 3460 €
Pre-tax: 2883 €
Join the waiting list
Geometry
| falcon disc | XS / 49 | S / 51 | M / 53 | L / 55 | XL / 57 |
|---|---|---|---|---|---|
| A / Effective Top Tube | 490 | 510 | 530 | 550 | 570 |
| B / Seat tube (c to c) | 440 | 450 | 470 | 495 | 515 |
| C / Chainstay | 405 | 405 | 405 | 405 | 405 |
| D / BB drop | 72 | 70 | 70 | 68 | 68 |
| E / Head tube | 96 | 110 | 125 | 155 | 175 |
| F / Reach | 352 | 364 | 370 | 377 | 391 |
| G / Stack | 510 | 523 | 537 | 566 | 587 |
| H / Wheelbase | 938 | 954 | 963 | 976 | 991 |
| I / Axle to crown | 368 | 368 | 368 | 368 | 368 |
| R / Fork rake | 45 | 45 | 45 | 45 | 45 |
| X / Seat tube angle | 75 | 74,5 | 73,5 | 73 | 73 |
| Y / Head tube angle | 72 | 72 | 72,5 | 73 | 73,5 |
Options
Direct 160mm flat mount bosses
included
Braze-on derailleur hanger
+ 55 €
Stainless steel brazed head badge
+ 35 €
Extra water bottle boss
+ 55 €
Located under down tube (seat tube and top of down tube included)
Located under down tube (seat tube and top of down tube included)
Integrated cable routing
+ 180 €
Custom guides depending on your groupset
Custom guides depending on your groupset
Integrated steel seat tube
+ 230 €
Comes its custom 3D printed aluminium seat mast
Comes its custom 3D printed aluminium seat mast
Custom stem
+ 320 €
Choose your length and stem angle
Choose your length and stem angle
Custom geometry
+ 150 €
Within our size chart, if you’re outside of the chart, we’ve got you covered for free!
Within our size chart, if you’re outside of the chart, we’ve got you covered for free!
Paint
Chameleon or Candy
Solid color painted logos
+ 180 €
Paint effect two colors
Solid color painted logos
+ 280 €
Paint effect one color
Solid color painted logos
+ 220 €
One color glitter
Solid color painted logos
+ 140 €
Three color fade
Solid color painted logos
+ 90 €
Two color fade
Solid color painted logos
included
Solid color
Solid color painted logos
included
Full custom on request (gold leaf, marble effect, splatter, chameleon fade or whatever you have in mind just get in touch with us and we will discuss it together)
Frameset pricing
from 3460 €
Pre-tax: 2883 €
Join the waiting list
