falcon caliper

Road rim brakes

Meet the falcon caliper

Specs

Tubing	Dedacciai Zero 25th anniversary
Dropouts	Paragon QR 9mm Stainless Steel
Fork	Wound up (4 to 6 months lead times) or Steel Colombus Max (no lead time)
Bottom bracket	BSC 68mm
Headset	External 1”1/8 (EC34/28.6 - EC34/30)
Seatpost diameter	27,2mm
Spacing	QR 9 x 100mm front, QR 9 x 130mm rear
Tire clearance	700 x 30 mm
Approximative weight	Around 1600 grams in size Medium (frame only)
Brakes	Caliper

Introducing the Falcon in its caliper version, a weight conscious steel road frame that delivers both elegance and performance. With its thinner, lightweight and stylish caliper braking system, this frame makes it perfect for riders who value classic design and unparalleled agility. The frame’s design is both beautiful and functional, making it a favorite among cycling enthusiasts. Built with some of the lightest steel tubes available today, this frame rides like a real feather giving you as much power as comfort allowing you to enjoy your bike for any kind of ride. Are you looking for a neo-retro bike with modern technologies but want to keep this invaluable timeless aesthetic? If so, the Falcon in its Caliper version is a bike that is aiming to exceed your expectations.

Frame features

Routing type

External

Front derailleur mount

Clamped

Welding type

Fillet brazed with a smooth filed finish

Chain Stays shape

Straight

Seat Stays Shape

Wishbone

Seat clamp

Brazed

Tube shape

Round and ovalized

Serial number

Stamp brass plate under the bottom bracket shell

Frameset pricing

from 3250 €

Pre-tax: 2708 €

Join the waiting list

Browse options below ↓

Learn more about the ordering process

Geometry

falcon caliper	XS / 49	S / 51	M / 53	L / 55	XL / 57
A / Effective Top Tube	490	510	530	550	570
B / Seat tube (c to c)	440	453	470	495	515
C / Chainstay	405	405	405	405	405
D / BB drop	72	72	70	68	68
E / Head tube	95	110	130	155	175
F / Reach	353	359	369	377	391
G / Stack	506	520	541	566	586
H / Wheelbase	942	957	966	974	991
I / Axle to crown	368	368	368	368	368
R / Fork rake	48	48	48	45	45
X / Seat tube angle	75	74	73,5	73	73
Y / Head tube angle	71,5	71,5	72,5	73	73,5

Options

Braze-on derailleur hanger

+ 55 €

Stainless steel brazed headbadge

+ 35 €

Columbus max tubing

+ 150 €

Columbus max steel fork

included

T47 68mm bottom bracket shell

included

Integrated steel seat tube

+ 230 €
Comes its custom 3D printed aluminium seat mast

Custom stem

+ 320 €
Choose your length and stem angle

Custom geometry

+ 150 €
Within our size chart, if you’re outside of the chart, we’ve got you covered for free!

Paint

Chameleon or Candy

Solid color painted logos

+ 180 €

Paint effect two colors

Solid color painted logos

+ 280 €

Paint effect one color

Solid color painted logos

+ 220 €

One color glitter

Solid color painted logos

+ 140 €

Three color fade

Solid color painted logos

+ 90 €

Two color fade

Solid color painted logos

included

Solid color

Solid color painted logos

included

Full custom on request (gold leaf, marble effect, splatter, chameleon fade or whatever you have in mind just get in touch with us and we will discuss it together)

Frameset pricing

from 3250 €

Pre-tax: 2708 €

Join the waiting list

Learn more about the ordering process
